Description
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/1.9″ progressive scan CMOS |
| Effective Pixels: | | | 2560(H)×1440(V) |
| Signal System: | | | PAL/NTSC |
| Minimum Illumination: | | | Color: 0.005 Lux @(F1.5, AGC ON) B/W: 0.0005 Lux @(F1.5, AGC ON) 0 Lux with IR |
| White Balance: | | | Auto / Manual |
| AGC: | | | Auto/Manual |
| BLC: | | | ON/OFF |
| HLC: | | | Support |
| Smart defog: | | | Support |
| WDR: | | | DWDR |
| Shutter Time: | | | 50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
| Day& Night: | | | ICR |
| Digital Zoom: | | | 16X |
| Privacy Masking: | | | 24 privacy masks programmable |
| Auto Focus: | | | Auto / Semi-automatic / Manual |
| Lens | ||
| Focal Length: | | | 5.7 mm to 205.2 mm, 36× Optical |
| Zoom Speed: | | | Approx. 4.4s (optical lens, wide-tele) |
| Angle of View: | | | Horizontal field of view: 51.1° to 1.7° (wide-tele) Vertical field of view: 31.3° to 1.0° (wide-tele) Diagonal field of view: 58.0° to 2.0° (wide-tele) |
| Minimum Working Distance: | | | 10-1500mm(Wide-Tele) |
| Aperture Range: | | | F1.5~F4.5 |
| Pan & Tilt | ||
| Pan Range: | | | 360°endless |
| Pan Speed: | | | Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s |
| Tilt Range: | | | -20°~90°(Auto Flip) |
| Tilt Speed: | | | Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s |
| Proportional Zoom: | | | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: | | | 300 |
| Patrol: | | | 8 patrols, up to 32 presets per patrol |
| Pattern: | | | 4 patterns, with the recording time not less than 10 minutes per pattern |
| Power loss recovery: | | | Support |
| Park Action: | | | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: | | | ON/OFF |
| Freeze Frame: | | | Support |
| Smart-tracking: | | | Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger |
| Wiper: | | | Optional |
| Infrared | ||
| IR irradiation distance: | | | 500m |
| IR irradiation angle: | | | Adjustable by zoom |
| Alarm | ||
| Alarm Input: | | | 7 Inputs |
| Alarm Output: | | | 2 |
| Alarm Actions: | | | Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Network | ||
| Ethernet: | | | 10Base -T, /100Base-TX, RJ45 Connector |
| Main Stream: | | | 50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: | | | 50Hz: 25fps(704×576, 640×480,352×288); 60Hz: 30fps(704×480, 640×480,352×240) |
| Third Stream: | | | 50Hz: 25fps(704×576, 640×480, 352×288); 60Hz: 30fps(704×480, 640×480, 352×240) |
| Video Compression: | | | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| ROI encoding: | | | Support |
| Audio Compression: | | | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Mode: | | | OFF/Audio input/Audio output |
| No. of Simultaneous Users: | | | Up to 20 users |
| Three-Stream: | | | Support |
| Mini SD Card: | | | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: | | | User authentication (ID and PW), Host authentication (MAC address) IP address filtering |
| Client GUI | ||
| Camera Control: | | | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: | | | Time: Week: Date, 6 formats on the Client |
| Client: | | | Support iVMS-4200 |
| Web Browser: | | | IE 7+, Chrome 18 – 42, Firefox 5.0 +, Safari 5.02 + |
| General | ||
| RS-485 Protocols: | | | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Consumption: | | | 24 VAC (Max. 60 W) Hi-PoE (Max. 50 W) |
| Working Temperature/Humidity: | | | -40°C ~ 65°C (-40°F ~ 149°F) |
| Protection Level: | | | IP66 Standard, IK10 (only supported by camera without wiper), TVS 6,000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions: | | | Φ 266.6 mm × 410 mm (Φ 10.50″ × 16.14″) |
| Weight (approx.): | | | 8kg (approx.17.64lb) |
