CP-TNW-GP8F2-12 8 Port PoE Switch

Description

• PoE ModeEnd-span
• Switch Capacity20Gbps
• ColorGray
• Surge Immunity6KV
• Uplink Ports2x 1000Base-X SFP Port
• Storage Temp-40℃~+85℃
• Storage Humidity5%-95%(Non-condensing)
• Buffer1M
• Exchange TypeStorage & Fowarding
• PoE OutputSingle PoE Output≤30W(54V DC), Whole machine PoE output≤120W
• Power Consumption5W
• PoE Power Supply1/2(+), 3/6(-)
• PoE Standard802.3af/at(PSE)
• Power SourceDC 48V~57V
• Net Weight(g)500g
• Dimension200mm x 101.8mm x 27mm
• Downlink Ports8×10/100/1000Base-T Ethernet Ports(PoE)
• ESD ProtectionContact discharge 6K, Air discharge 8KV, Per: IEC61000-4-2
• Packet Forwarding Rate14Mpps
• Operating Temperature-10℃~+45℃
• MAC Address List4K
