Description
- Image Sensor1/3″ 3MP PS CMOS Image Sensor
- Minimum Illumination0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on)
- Effective Pixels2304(H) x 1536(V)
- Shutter SpeedAuto/Manual, 1/3(4)~1/100000s
- White BalanceAuto/Manual
- Lens3.6mm (2.8mm optional)
- AGC ControlAuto/Manual
- Video CompressionH.264/ H.264H/ H.264B
- S/N RatioMore than 50dB
- Back Light Comp.BLC/ HLC/ DWDR
- Resolution3M(2048×1536)(2304×1296)/1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480) /CIF(352×288/352×240)
- Frame RateMain Stream: 3M(1 ~ 20fps)/1080P(1 ~ 25/30fps) , Sub Stream: D1(1 ~ 25/30fps)
- ICRAuto(ICR)/Color/B/W
- Bit RateH.264: 4kbps~8192kbps
- ProtocolIPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS ONVIF, PSIA, CGI
- User Account20 Users
- Smart PhoneiPhone, iPad, Android Phone
- IRIR Range of 30 Mtr.
- Micro SDMicro SD Max 128GB
- Operating Temperature-30°C~+60°C , Less than 95%RH
- Power SourceDC12V, PoE (802.3af)
- Power Consumption<4W(IR on)
- Weatherproof StandardIP67 & IK10
- DimensionΦ110mm×81mm
- Weight0.34Kg (with package 0.47Kg)
