Description
- ProcessorDual-core embedded processor
- Operating SystemEmbedded LINUX
- IP Camera Input32 channel
- Two-way Talk1 channel Input, 1 channel Output, RCA
- User InterfaceGUI
- Video Output1 HDMI, 1 VGA
- CompressionH.265/H.264
- Video Resolution3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768
- Motion DetectionMD Zones: 396(22×18).
- Video Losssupports
- Camera Blanksupports
- Alarm Input16 Channel, Low Level Effective, Green Terminal Interface
- Alarm Output4 Channel, NO/NC Programmable, Green Terminal Interface
- Hard Disk4 SATA III ports, up to 24TB
- Smart PhoneiPhone, iPad, Android Phone
- Trigger EventsRecording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
- Recording ModeManual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
- Search ModeTime/Date, Alarm, MD & Exact search (accurate to second), Smart search
- PlaybackPlay, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom
- Backup ModeUSB Device/Network
- Interface Ports1 HDMI, 1 VGA, 2 USB (1USB 3.0), 1 RS485, 1 RS232, 1 RJ45
- Record Interval1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Max User Account128 users
- Ethernet1 RJ-45 port (10/100/1000Mbps), 1 Independent 1000Mbps Ethernet Port
- ProtocolsHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, IP Search, ONVIF 2.4, CGI Conformant
- Power SupplyAC 100~240V, 50/60 Hz
- Power Consumption<13.7W (Without HDD)
- Working Temp-10 ~+55°C / 10~90%RH / 86~106kpa
- Dimension440mm x 411.1mm x 76mm
- Weight4.7kg (without HDD)
